Denver & Rio Grande Western class C-16

originally class 60N

United States 1877 96 produced
No. 220 in 1920 in Embudo, New Mexico Otto Perry / Denver Public Library PD

The Denver & Rio Grande had the class 60N built by Grant and Baldwin as standard freight locomotives starting in 1877. These were Consolidations, which were tiny compared to later locomotives on the three-foot gauge. Baldwin's locomotives had a larger boiler than Grant's. They later received the class designation C-16 from the Denver & Rio Grande Western. Some later received slightly larger wheels and higher boiler pressure. After the new Mikados took over the majority of traffic, the Class 60N was significantly decimated in the 1930s. It could only remain in use where no other locomotives could be used due to the axle load. Today Grant's number 223 remains, having been under restoration for years.

Technical data

General

Property Grant Baldwin
Built 1877-1882
Manufacturers Grant Baldwin
Wheel arrangement 2-8-0 (Consolidation)
Gauge 914 mm (Three feet)

Dimensions and weights

Property Grant Baldwin
Wheelbase 5.28 m 5.44 m
Total wheelbase 12.78 m 12.74 m
Service mass 27.2 t
Adhesion mass 22.7 t
Total mass 50.6 t
Rigid wheelbase 3.45 m
Axle load 5.7 t
Water capacity 9,464 l
Fuel capacity 5.4 t (coal)

Boiler

Property Grant Baldwin
Grate area 1.301 m² 1.551 m²
Firebox surface 6.689 m² 8.175 m²
Tube heating surface 70.513 m² 70.978 m²
Evaporative heating surface 77.203 m² 79.153 m²
Total heating surface 77.2 m² 79.2 m²

Power plant

Property Grant Baldwin
Driver diameter 914 mm
Boiler pressure 9 bar
Expansion type simple expansion
Cylinders two, 381 x 508 mm

Power

Property Grant Baldwin
Power source steam
Estimated power 164 kW 201 kW
Starting effort 61.4 kN

Calculated values

Property Grant Baldwin
Factor of adhesion 1 : 3.62
Optimal speed 16 km/h 19 km/h
Power-to-weight ratio 6.0 kW/t 7.4 kW/t
Heating Surface Equivalent 110.6 m² 120.0 m²
Cylinder volume/HSE 1 : 1,046.87 1 : 965.05
Adhesive weight/Total 1 : 1.20
Tractive force/Heating surface 1 : 16.62 1 : 16.21
Grate area/Heating surface 1 : 59.34 1 : 51.03
Firebox/Tube surface 1 : 10.54 1 : 8.68
