Micheline
France | 1933
Micheline Typ 22
Micheline Typ 22
Varianttype 16types 20 to 22typ 23type 33
General
Built19331934-19371936
ManufacturerMichelin
Axle configC-3 D-4 4-D-4 4-D-D-4
Gauge4 ft 8 1/2 in (Standard gauge)
Seats365696108
Dimensions and Weights
Length50 ft 2 3/4 in56 ft 9 1/2 in99 ft 7 1/4 in148 ft 3 1/2 in
Empty weight16,094 lbs32,628 lbs
Boiler
Varianttype 16types 20 to 22typ 23type 33
Power Plant
Power
Power sourcepetrol-mechanic
Top speed56 mph65 mph84 mph
EngineHispano-SuizaPanhardHispano-Suiza
Engine typeV12 petrol2x V12 petrol
Engine output217 hp (162 kW)247 hp (184 kW)662 hp (494 kW)493 hp (368 kW)
Calculated Values
petrol railcar
long distance
regional
rubber tires
last changed: 10 2023
