Polish State Railways Ty246
go back
Poland | 1947
100 produced
No. 91, built by Lima, on a works photo
No. 91, built by Lima, on a works photo
flickr/Historical Railway Images

After the end of World War II, the Polish State Railway ordered heavy 2-10-0 locomotives for coal traffic between Upper Silesia and the Baltic port of Gdynia. Although they technically differed from domestic locomotives in many ways, they could be produced faster than Polish or European manufacturers in general could offer. They were paid for with funds from the UNRRA and 40 locomotives from ALCO, 40 from Baldwin and 20 from Lima were all delivered in 1947.

These locomotives could only be used on main lines due to their axle load of 21.5 tonnes. They had a comfortable, closed cab and could be driven while being seated. The fireman was also relieved by a mechanical stoker. Other features were a steam reverser and a Worthington feed water heater.

They were designated Ty246 and quickly gained the nickname “Trumans” and usually hauled coal trains with a weight of around 2,200 tonnes. Their limit in regular traffic was 2,800 tonnes with a speed of 40 km/h. Their active service ended in 1979 and today, Ty246-22 is on static display in the Museum at Karsznice.

General
Built1947
ManufacturerALCO, Baldwin, Lima
Wheel arr.2-10-0 (Decapod)
Gauge4 ft 8 1/2 in (Standard gauge)
Dimensions and Weights
Length78 ft 6 15/16 in
Rigid wheelbase22 ft 0 3/16 in
Empty weight234,792 lbs
Service weight257,941 lbs
Adhesive weight222,667 lbs
Total weight426,814 lbs
Axle load47,399 lbs
Water capacity8,454 us gal
Fuel capacity308,647 lbs (coal)
Boiler
Grate area67.8 sq ft
Firebox area225 sq ft
Tube heating area2,518.8 sq ft
Evaporative heating area2,743.7 sq ft
Superheater area1,038.7 sq ft
Total heating area3,782.4 sq ft
Power Plant
Driver diameter57.1 in
Boiler pressure232 psi
Expansion typesimple
Cylinderstwo, 25 x 27 9/16 in
Power
Power sourcesteam
Estimated power2,682 hp (2,000 kW)
Top speed50 mph
Starting effort59,525 lbf
Calculated Values
steam locomotive
freight
last changed: 07/2025
